Camera
|
|
Photographing Area
|
A4
|
|
Focus Mode
|
AF auto focus
|
|
White Balance
|
Auto adjustment
|
|
Color Compensation Mode
|
Auto adjustment
|
|
Imaging Distance
|
150 mm–260 mm
|
|
Total Pixels
|
13 MP
|
|
Effective Pixels
|
13 MP
|
|
Video Output Format
|
MJPG, YUV2 (third-party software)
|
|
Maximum Output Frame Rate
|
4168 × 3126/10 fps
|
|
Lens Distortion
|
<1.5%
|
|
Default Output Resolution
|
4168 × 3126
|
|
Supportive Output Resolution
|
MJPG format resolution:
4168 × 3126, 4160 × 3120, 3840 × 2160, 3264 × 2448, 2592 × 1944, 2048 × 1536, 1920 × 1080, 1600 × 1200, 1280 × 720, 1024 × 768, 640 × 480
YUY2 format resolution:
1920 × 1080, 1600 × 1200, 1280 × 720, 1024 × 768, 800 × 600, 640 × 480
|
|
Device Ports
|
|
USB Port
|
1 × USB-A (USB 2.0)
|
|
Function
|
|
Illuminator
|
5 adjustable brightness levels
|
|
Gestures
|
Supports moving images with your fingers, scaling with 2 fingers and erasing with the swiping gesture.
|
|
Annotation
|
6 selectable colors
|
|
Eraser
|
3 eraser sizes and one-click clear page
|
|
Rotation
|
Supports rotating the screen 90 degrees with one click.
|
|
|
Images are automatically optimized after switching to the AI photo function (the tablet device should be connected to the booth)
|
|
Album
|
The images will be automatically saved to the album when AI photo is turned on. You can click any of the images to view and rotate them, make annotations, and more.
Import the images from OPS to the album in the whiteboard. It supports saving annotated images and performing split screen (6 windows), which helps with making comparisons during teaching. You can also erase annotations, use full screen view, zoom in and out, rotate images, save, and replace images.
|
|
Tools
|
Supports zooming in and out of images, and adjusting their brightness, contrast and saturation.
Settings:
1. Frames Tab: Supports enabling and disabling panoramic mode, motion, HDV and screen lock.
2. Photo Tab: Supports enabling and disabling AI photo, smart photo, comparison, and burst mode. Burst mode has 3 options: smart, 5 sec and 10 sec.
3. Routine Tab: Supports enabling and disabling device model, resolution, and tips, and selecting the toolbar (bottom/2 sides), focus (lock/auto), and language (Chinese/English).
Device information can also be displayed.
|
|
Aerial View
|
Supports displaying images on the whiteboard and navigating within large images.
|
|
Minimization
|
Windows can be minimized.
|
|
Camera
|
|
Power Supply
|
USB
|
|
Voltage
|
5 VDC
|
|
Current
|
<500 mA
|
|
Power Consumption
|
≤2.5 W
|
|
Standby Power Consumption
|
≤0.25 W
|
|
Operating Temperature
|
–15 °C to +45 °C (+5 °F to +113 °F)
|
|
Storage Temperature
|
–20 °C to +60 °C (–4 °F to +140 °F)
|
|
Operating Humidity
|
0%–93%, 101 KPa
|
|
Storage Humidity
|
0%–95%, 101 KPa
|
|
Product Dimensions
|
When open, 388 mm × 385 mm × 270 mm (15.28″ × 15.16″ × 10.63″);
When closed, 380 mm × 70 mm × 270 mm (14.96″ × 2.76″ × 10.63″)
|
|
Packaging Dimensions
|
326 mm × 105 mm × 454 mm (12.83″ × 4.13″ × 17.87″)
|
|
Net Weight
|
1.45 kg (3.20 lb)
|
|
Gross Weight
|
3.9 kg–4.1 kg (8.60 lb–9.04 lb)
|
|
Installation Method
|
Wall mount
|
|
Packing List
|
4 × expansion glue plugs, 4 × expansion bolts, 1 × USB connection cable, 1 × video booth, 1 × quality certificate, 1 × cable cover, 1 × wall-mount box, 2 × cable cover screws, 4 × PE wall-mounted bracket screws, 2 × glue plugs, 2 × keys
|
