Built-in System
|
|
Operating System
|
Android 11
|
|
CPU
|
Quad-core A73 + Quad-core A53
|
|
CPU Frequency
|
2.2GHz + 2.0GHz
|
|
GPU
|
ARM Mali-G52 MP8 (8EE)
|
|
RAM
|
8 GB
|
|
ROM
|
64 GB (optional 128 GB)
|
|
LCD Panel
|
|
Panel Dimensions
|
65 inch; 75 inch; 86 inch
|
|
Backlight
|
DLED
|
|
Aspect Ratio
|
16:09
|
|
Brightness
|
400 cd/m² (typ.)
|
|
Static Contrast
|
VA: 4000 (typ.); IPS: 1200 (typ.)
|
|
Resolution
|
3840 × 2160
|
|
Viewing Angle
|
178°(H) / 178°(V)
|
|
Lifespan
|
50,000 hours
|
|
Display Color
|
1.07 B/10 bit (8 bit + FRC)
|
|
Response Time
|
8ms (typ.)
|
|
Refresh Rate
|
60 Hz
|
|
Plug-in Camera (sold separately)
|
|
Plug-in Camera
|
48 MP
|
|
Auto Control
|
Auto white balance
|
|
Distortion
|
–8.6%
|
|
Max. Resolution
|
3840 × 2160@30 fps
|
|
Field of View
|
H: 87°; V: 49°; D: 99°
|
|
Device Ports
|
|
Light Sensor
|
Yes
|
|
Front Button
|
8 buttons (power, home, menu, signal source, touch lock, curtain, volume, and annotation)
|
|
Front Ports
|
Type C × 1 (4K@60 Hz, Touch, 65 W)
HDMI In × 1 (4K@60 Hz)
USB 3.0 Type-B × 1 (Touch)
USB 3.0 Type A × 2
Mic In × 1 (3.5 mm port)
|
|
Rear Port
|
Type C × 1 (4K@60 Hz, Touch, 15 W)
HDMI In × 2 (4K@60 Hz)
VGA In × 1 (1080p@60 Hz)
DP In × 1 (4K@60 Hz)
USB 3.0 Type-B × 3 (Touch)
HDMI Out × 1
USB 3.0 Type A × 2
USB 2.0 Type A × 1
Micro USB × 1
RS-232 × 1
RJ-45 In × 1
RJ-45 Out × 1
Audio In × 1 (3.5 mm port, used to play sound with VGA)
Audio Out × 1 (3.5 mm port)
SPDIF Out × 1 (Optical port)
OPS slot × 1
|
|
Function
|
|
IR Receiver
|
Yes
|
|
Bluetooth
|
Bluetooth 5.2
|
|
Wi-Fi
|
WIFI 5, 2.4 GHz/5 GHz; Integrated Wi-Fi 802.11 a/b/g/n/ac, supports PEAP/EAP-GTC authentication protocol within 802.l×
|
|
Wireless Access Point
|
WIFI 6, 2.4 GHz/5 GHz; Supports enabling hotspot and Wi-Fi at the same time
|
|
Touchscreen
|
|
Touch Technology Type
|
Infrared touch technology
|
|
Attachment Method
|
Zero Air Gap
|
|
Response Time
|
≤10 ms
|
|
Touch Points
|
Android: 32, Windows: 40
|
|
Touch Accuracy
|
± 1 mm (0.04″) (over 90% area)
|
|
Valid Touch
|
2 mm (0.08″)
|
|
Touch Height
|
3 mm (0.12″)
|
|
Writing Mode
|
Finger + Pen
|
|
Communication Mode
|
USB
|
|
Anti-light Interference
|
Anti-dazzle tempered glass
|
|
Surface Hardness
|
8H
|
|
Touch Resolution
|
32767 × 32767
|
|
Speaker
|
|
Built-in Speaker
|
3
|
|
Power
|
2.1 channel
front-end: 2 × 15 W (Ma×.)
Back-end: 20 W (Ma×.)
|
|
Frequency
|
20 kHz–200 kHz
|
|
Microphone
|
|
Microphone
|
8-array
|
|
Pick-up Distance
|
6 m–10 m (19.69 ft–32.81 ft )
|
|
AGC
|
Yes
|
|
Echo Cancellation
|
Yes
|
|
Polar Pattern
|
Omni-directional
|
|
Intelligent Noise Filtering
|
Yes
|
|
General
|
|
Power Supply
|
100–240 VAC, 50/60 Hz
|
|
Power Consumption
|
65-inch: 120 W (typ.); 300 W (ma×.);
75-inch: 150 W (typ.); 350 W (ma×.);
86-inch: 250 W (typ.); 500 W (ma×.)
|
|
Standby Power Consumption
|
≤0.5 W
|
|
Operating Temperature
|
0 °C to +40 °C (+32 °F to +104 °F)
|
|
Storage Temperature
|
–10 °C to +50 °C (+14 °F to +122 °F)
|
|
Operating Humidity
|
10%–90% (RH)
|
|
Storage Humidity
|
10%–90% (RH)
|
|
Product Material
|
Metal
|
|
Glass
|
4 mm Anti-dazzle tempered glass
|
|
Casing Color (Frame/Rear)
|
Bottom/top: Silver; left/right: black; back: black
|
|
Product Dimensions
|
65-inch: 1,485.2 mm × 93.0 mm × 924.5 mm
(58.47″ × 3.66″ × 36.40″)
75-inch: 1,707.5 mm × 93.0 mm × 1,050.0 mm (67.22″ × 3.66″ × 41.34″)
86-inch: 1,953.2 mm × 93.0 mm × 1,187.9 mm (76.90″ × 3.66″ × 46.77″)
|
|
Packaging Dimensions
|
65-inch: 1,580.0 mm × 200.0 mm × 1030.0 mm (62.20″ × 7.87″ × 40.55″)
75-inch: 1,800.0 mm × 200.0 mm × 1,165.0 mm (70.87″ × 7.87″ × 45.87″)
86-inch: 2,050.0 mm × 200.0 mm × 1,310.0 mm (80.71″ × 7.87″ × 51.57″)
|
|
Net Weight
|
65-inch: 42 kg (92.60 lb)
75-inch: 54 kg (119.05 lb)
86-inch: 70 kg (154.33 lb)
|
|
Gross Weight
|
65-inch: 52 kg (114.64 lb)
75-inch: 68 kg (149.92 lb)
86-inch: 85 kg (187.40 lb)
|
|
Holes Distance
|
65-inch: 500 mm × 400 mm (19.69″ × 15.75″)
75-inch: 600 mm × 400 mm (23.62″ × 15.75″)
86-inch: 800 mm × 400 mm (31.50″ × 15.75″)
|
|
Installation
|
Wall mount; mobile bracket
|
|
Packing List
|
Smart interactive whiteboard × 1
Power cord × 1
Passive stylus pen × 2
HDMI cable × 1
Quick start guide × 1
Wall mount bracket (already installed on the whiteboard) × 1
Accessory package × 1
Remote control × 1
Legal and Regulatory Information × 1
|
|
Certification
|
|
Certifications
|
CB, CE, Energy Star, ROHS, REACH, WEEE
|
